FPGA Boards

DIGITAL SIGNAL PROCESSING

Take advantage of FPGA cards built on open standards and with a high degree of configurability in order to address a wide range of applications - without the expense and extensive development time of custom in-house developments.

Product Name Form Factor FPGA Family Mezzanine Memory
FlexVPX 3U VPX backplane FlexVPX Backplane VPX 3U
FM780 FPGA board FM780 XMC FPGA Card XMC Virtex-7 Optional FMC site 2 GB DDR3 SDRAM and configurable memory options with 2 BLAST sites
PC720 PC720 FPGA Card PCI Express Kintex-7 1x HPC FMC, 1x LPC FMC 1 GB DDR3 SDRAM
PC820 PC820 FPGA Card PCI Express Ultrascale Kintex or Virtex 1x HSPC/FMC+ 8 GB DDR4-2133 SDRAM SO-DIMM
PC821 PC821 PCIe FPGA Card PCI Express Ultrascale Kintex or Virtex 1x HSPC/FMC+, 1x HPC FMC 8 GB DDR4-2133 SDRAM SO-DIMM
VP430 RFSoC Board VP430 RFSoC Board VPX 3U Zynq Ultrascale+ RFSoC 8GB DDR4
VP460 VPX 6U Zynq Ultrascale+ RFSoC + Zynq Ultrascale+ HBM 20GB Available
VP680 FPGA Card VPX 3U Virtex-6 Optional FMC site 3GB DDR3 with 3 BLAST sites
VP780 FPGA Card VPX 3U Virtex-7 1x HPC FMC 10 GB DDR3 SDRAM
VP868 VP868 FPGA Card VPX 6U 2x Ultrascale Kintex or Virtex 2x HSPC/FMC+ 36 GB DDR3 SDRAM with ECC
VP869 6U VPX FPGA Board VP869 FPGA Card VPX 6U 2x Virtex Ultrascale+ 2x HSPC/FMC+ 18GB DDR3 SDRAM with ECC
VP880 / VP881 FPGA Board VP880 / VP881 VPX 3U Ultrascale Kintex or Virtex 1x HSPC/FMC+ 10GB DDR4
VP889 FPGA Board VP889 FPGA Board VPX 3U Virtex Ultrascale+, Zynq Ultrascale+ 1x HSPC/FMC+ 10GB DDR4

FPGA BOARDS products that are No Longer Recomended or Discontinued see below.

Product Name Description
FC6301 FPGA Card

The FC6301, featuring a Virtex-6 FPGA, is a high performance cPCI card with advanced digital signal processing capabilities.
FM481 Mezzanine Card

The FM481 is a high performance PMC/XMC module dedicated to high bandwidth communication. In addition to 4x 2.5Gbps optical transceivers for fiber channel and Gigabit Ethernet, the FM481 offers fast on-board memory resources and one Virtex-4 FX20/60 FPGA. The FM481 is based on the success of the FM482.
FM680 Mezzanine Card

The versatile FM680 is a high performance Xilinx Virtex™-6 based XMC industry standard VITA 42.3-compliant module.

Abaco Advantage

What we can do for you.

FIND OUT MORE

Product Selector

Find exactly what you're looking for.

SELECT PRODUCTS

FPGA DSP Board Support Package

Our FPGA DSP Board Support Package gives you complete control, flexibility and power to develop solutions for the most demanding DSP applications. It's built upon pre-validated IP blocks that have been designed to minimize FPGA resource utilization - giving you as much programmable logic for your application as possible.
