We did what you wanted us to do.

The VP889: when we promise upgradability, we deliver upgradability.

VP889 FPGA Board

Our modular approach is your lower cost of ownership

Why upgrade a whole system when Abaco lets you upgrade only the elements you need?

Features

Processing

  • User Programmable Virtex Ultrascale+
  • Zynq Ultrascale+ MPSoC

MEMORY

  • 8 GB DDR4 mapped to FPGA
  • 2GB DDR4 mapped to Zynq

ANALOG AND DIGITAL I/O

  • 1x HSPC/FMC+ Site for Analog or Digital Input/Output

FLEXIBLE BACKPLANE OPTIONS

  • VITA 67.1 analog interface ports
  • VITA 66.4 Optical Interface via Firefly BLAST site (optional)

COOLING OPTIONS

  • Air, Conduction cooling (optional)
imgnum - 0imgnum - 1imgnum - 2imgnum - 3imgnum - 4imgnum - 5

Built with security in mind

Leverage encrypted bit streams and secure boot that come built in.

Operating Temp: (Level 1)

Slot Pitch: 0.8" (air cooled) or 1.0"

Form Factor: 3U VPX

More performance per watt, more computational resources for your toughest DSP applications

State of the art FPGA technology for rapidly changing applications.

Download White Paper     BLOG POST

The flexibility you need for the system you want

Choose your FPGA. Choose your I/O. Configure to your requirements.

Specifications

Form Factor
VPX 3U
Cooling
Air, Conduction
Mezzanine
1x HSPC/FMC+
Conformal Coating
Option
I/O Types
Multi-channel A/D and D/A using FMCs
Operating System (OS) Support
Linux, VxWorks, Windows
Memory
10GB DDR4
FPGA Family
Virtex Ultrascale+, Zynq Ultrascale+
