GRA115Q

NVIDIA® Quadro RTX™ 5000 or Quadro RTX™ 3000 Graphics Output and GPGPU Board

GRA115Q

Overview


Leading Technology

The GRA115Q is a rugged 3U VPX graphics output and high-performance computing GPGPU board based on the NVIDIA Turing™ architecture. It is an ideal solution for graphics/display processing applications such as situational awareness, and moving map applications as well as general purpose graphics processing unit (GPGPU) applications such as radar and video surveillance/analysis.

Flexible

The GRA115Q is available with your choice of an NVIDIA Quadro RTX™ 5000 or Quadro RTX™ 3000 GPU which can result in a 4X performance improvement over NVIDIA Pascal™ class GPUs. At peak performance, the RTX5000 provides up to 9.49 TFLOPS of single precision floating point compute performance (FP32).

Rugged by Design

By soldering the GPU directly onto the VPX card, the GRA115Q boasts an extremely rugged chip-down design, and brings the power of NVIDIA®

and CUDA® without a multi-chip module.

Technology Insertion Patch

For high-end graphics output applications such as display computing the GRA115Q provides quad graphics outputs which can be configured as two DisplayPort 1.4a outputs and two SL-DV outputs, four SL-DVI outputs or four DisplayPort 1.4a outputs. The SL-DVI outputs are pincompatible with the GRA112D, GRA113D, GRA112Q, GRA113Q and the GR5 3U VPX graphics boards, providing customers with a straightforward, cost-effective upgrade to the higher performance and increased longevity of the new board.

AXIS Software Toolkit

AXIS ImageFlex is an image processing and visualization toolkit enabling the rapid development of high performance image processing, visualization and autonomy applications aimed at size, weight and power (SWaP) sensitive platforms. It is focused on high performance GPU processing and graphics with interoperability with other programming paradigms such as OpenGL, OpenCL™, CUDA and OpenCV.

Block Diagram

Specifications

Form Factor
VPX 3U
I/O
2x DisplayPorts 1.4a outputs, 2x SL-SVI outputs, 4x SL-DVI outputs
Application
Rugged, Video & Graphics
Cooling
Air, Conduction
Chip Set
NVIDIA QuadroRTX™ 3000 GPU, NVIDIA QuadroRTX™ 5000 GPU
Conformal Coating
Yes
Extended Temperature Range
From -40° to +85°C
Control Interface
PCIe
Operating System (OS) Support
CUDA, Linux, NVIDIA CUDA, OpenCL, OpenGL, Windows 7, Windows 10
Video Output
DVI
AXIS Support
Yes
Expansion Plane
PCIe Gen 3
Ruggedization
Rugged Air Cooled and Conduction Cooled
