VPX360 3U VPX Development System

Performance, flexibility, and scalability

Overview


The VPX360 is a 3U VPX 6-slot system dedicated to high-speed signal processing and computing applications. The VPX360 system slot is populated with an SBC comprising a dual core i7 Intel processor, up to 8GB of DDR3 SDRAM, two Ethernet ports, and a DVI Display Port. All remaining five expansion slots communicate with the host via PCIe and can be used for high-end, 3U, OpenVPX-compliant cards.

With a backplane optimized for fast inter-slot communication in excess of 6 GB/s between any two adjacent slots in the system, the VPX360 offers a combination of flexibility and high performance in a small footprint. OpenVPX cards from third-party vendors or 3U VPX products from 4DSP can be used in the VPX360.

Specifically, the VP780 with a Virtex-7 FPGA and an FMC site offers I/O versatility and processing power that makes it suitable for any application.

Specifications

Form Factor
VPX 3U
Processor
Intel Core i7
Cooling
Air
I/O Types
Multi-channel A/D and D/A using FMCs
User Programmable FPGA
Kintex-7
