MAGIC1A

Intel Xeon E Processor and NVIDIA Quadro GPU.
MAGIC1A

Overview

The MAGIC1A is a rugged line replaceable unit (LRU) suitable for high-performance computing in the harshest of environments. The combination of Intel and NVIDIA processors in a low SWaP-C3 package ensure it can be used across a wide range of Commercial and Military applications, including Displays, Situational Awareness, Data/RADAR Processing, Video Processing, Classification, and Artificial Intelligence.

High Performance, High Reliability

The MAGIC1A combines an Intel Xeon E3 v6 CPU and a NVIDIA Quadro P2000 GPU to provide an ideal platform for both runtime performance and ease of programming. The quad-core CPU and 768-core GPU connected by Gen 3 PCI Express are capable of up to 2.3 TFLOPS floating point performance. The MAGIC1A leverages technologies provided by the CPU and GPU; Intel TurboBoost Technology, Intel AVX 2.0 extensions and AES NI instructions, Hyper-Threading Technology, NVIDIA CUDA 10, OpenCL 1.2, DirectX® 12, OpenGL and H.265 (HEVC)/H.264 hardware encode/decode.

Extensive I/O

The MAGIC1A has extensive I/O to enable its use in a variety of deployed situations, including Ethernet, USB, ANSI TIA/EIA serial communications, Display Port and DVI video output, MIL-STD-1553 and ARINC 429 avionics protocol interfaces, and general purpose I/O.





Specifications

1553 # Channels:
4
Analyzer
BusTools
Application
Video & Graphics, Embedded
AXIS Support
Yes
Conformal Coating
Yes
Control Interface
Ethernet
Cooling
Base Plate
Environmental
MIL-STD-810G, MIL-STD-704
Ethernet
1000BaseT
Extended Temperature Range
Yes
Fans
1
Form Factor
3U Boxed, VPX 3U
Function
High Capacity Disk
Hard Disk
Optional
I/O
ARINC 429, DisplayPort, DVI, MIL-STD-1553, VGA, RS 232/422/485, 1 Gigabit Ethernet, Audio I/O and GPIO
Management Plane
IPMI (Baseboard Man. Controller)
Military Specifications
MIL-D38999 connectors
Operating System (OS) Support
Linux, Windows 10, VxWorks 7
Operating Temp
-40˚C to +60˚C
Options/ Notes
*VxWorks - SBC support only
Processor
Intel Xeon E3-1505M, E3-1505L v6
RoHS
Yes
Ruggedization
Level 4-5 Conduction Cooled
Serial I/O
2
Slots
2
Software
BIT, AXIS ImageFlex
Weight lb (kg)
11 (5)
