CEI-715

ARINC 429 Interface for PCMCIA

CEI-715

This product reached the end of its lifecycle (end-of-life) on May 30, 2012

Please refer to downloads section below if you require documentation or software. If you have any questions or require product support, including help migrating to our latest products, please contact us.
To see all end of life products CLICK HERE.

Overview


The CEI-715 is an intelligent, high-density, Type II PC Card (PCMCIA) interface that provides up to 12 fully independent ARINC 429/575 channels, along with up to 4 bi-directional avionics-level I/O discretes. Features include programmable data rates and parity, error detection, multiple buffering modes, time-tagging and automatic transmit slew rate adjustment. Also, BusTools/ARINC, our flexible, Windows-based GUI Bus Analyzer, and LabVIEW support is optionally available.

** This product is no longer recommended for new designs that require long term product availability. The replacement product is our RCEI-715A.





  • 4 bi-directional avionics-level discretes
  • Easy-to-use BusTools/ARINC Windows-based GUI Bus analyzer available
  • Configuration available with ARINC 429, avionics-level discretes
  • Up to 8 Rx, 4 Tx ARINC 429 channels
  • Available with ARINC 429, 573, 717, CSDB and ARINC 561 6-wire on same card
  • Support for LabVIEW





Specifications

Form Factor
PCMCIA
Application
Notebook Portable
# ARINC Channels
2 to 8
Temp Range
Commercial
Analyzer
BusTools
Protocol
717
