NETernity™ CP3-GESW8

NETernity 3U CPCI 8-port Unmanaged Gigabit Ethernet Switch

This product entered a Restricted Production Phase (RPP) on May 5, 2011

Please refer to downloads section below if you require documentation or software. If you have any questions or require product support, including help migrating to our latest products, please contact us.
To see all end of life products CLICK HERE.

We recommend the following alternative solutions:

Overview

NETernity™ CP3-GESW8 is a 3U CompactPCI (CPCI) 8-port unmanaged Gigabit Ethernet switch with low power consumption. This switch has one front-panel RJ-45 connector and seven ports accessed via rear panel I/O (J2 connector). The switch allows easy setup and switch operation in 10/100/1000BaseT Ethernet. An onboard serial EEPROM is used for configuration of the switch's registers during power on initialization. The switch provides 1MB of packet buffer memory and has advanced address management features including address learning and aging that allows a high-speed non-blocking switch operation.





  • One front panel port
  • IEEE 802.3 compliant
  • 8-port 10/100/1000BaseT Ethernet line speed switching
  • Standalone board, no host CPU intervention required
  • Easy setup and operation
  • Seven rear access ports
  • Not recommended for new designs





Specifications

Form Factor
cPCI 3U
Management Type
Unmanaged Layer-2
Port Type
10/100/1000BaseT
Ports
8
